Carat Rainwater Harvesting System 2700l, 3750l, 4800l and 6500l
This system is available for inspection at the Centre for Water Saving Technology. We highly recommend inspecting this product, particularly the pump, as the main components are significantly higher quality than anything else on the market.
If you need assistance with tank sizing use our rainwater harvesting calculator here or our garden rainwater tank sizing blog here.
Four main rainwater harvesting packages are offered in four tank sizes and two lid options:
1. Garden Comfort Package for irrigation only
2. Direct Rainwater Harvesting System - the most cost effective solution. A submersible pump maintains pressure and delivers rainwater where it is required. A mains top up unit, tops up the tank if it runs low on rainwater.
3. Indirect Rainwater Harvesting System - the submersible pump tops up a header tank which drains by gravity to feed rainwater to where it is required. The header tank has a mains top up valve if rainwater runs low.
4. Eco Plus Rainwater Harvesting Package - An external pump and console draws rainwater from the tank and deliver it to where it is required. If the tank is low on rainwater a small amount of mains water is delivered to the console and the pump continues to deliver this water.
1. Freeflush Garden Comfort Package
Garden Comfort scope of supply:
- Carat® tank incl. 4 prefitted DN 100 lip seals
- Tank cover suitable for pedestrian or vehicle loading depending on the version
- Tank filter package for the garden consisting of:
- Internal filter basket incl. suspension
- Overflow siphon with integrated rodent guard
- Garden-Comfort technical package consisting of:
- Integra INOX stainless steel submersible and suction pump incl. floating extraction setup
- 10m pressure hose 1"
- Internal water connection box
- External water connection box
2. Freeflush House Direct -Supply Package
- Simple & quick to install
- Submersible pump supplies harvested rainwater on demand to WCs, washing machine & external tap
- CaratThe quiet & conveniently sized Mains-on-Tap unit will fit in a kitchen or utility cupboard for very low visual impact
- Innovative float sensor detection on Mains-on-Tap unit ensures that the underground tank is kept supplied with mains water but only the amount necessary to maintain supply to toilets and washing machine, leaving as much volume as possible in the tank to collect rainwater when available
House Direct scope of supply:
- Underground tank (choice of tanks available, sizes vary according to property type)
- Telescopic lid (choice of telescopic lid available, depending on tank location)
- Filter (Minimax filter supplied in accordance with type of tank)
- Submersible pump with floating water intake
- Mains-on-Tap unit
- Float sensor (connected from Mains-on-Tap unit to the underground tank)
- 100mm diameter duct pipe to contain; float sensor cable, power cable for pump, also bringing mains water to underground tank as and when required
3. Freeflush House Indirect -Supply Package
The reliable domestic solution with a submersible pump and header tank system
- Simple & quick to install
- Submersible pump supplies harvested rainwater on demand to the header tank where it is then gravity fed to the WCs & washing machine
- The header tank controls the operation of the system and the supply of harvested rainwater and backup mains water to the WCs
- Dual valve system within the header tank prioritises rainwater supply over mains water, maximising the use of all available rainwater to save on mains water consumption
- Mains water switch over point is at a lower level in the header tank when rainwater is not available from the underground Carat tank
- Mains water backup supply is not reliant on power supply or pump pressure and therefore guarantees supply of water to WCs at all times
House Indirect scope of supply:
- As per direct package
- As per direct package
- As per direct package
- As per direct package
- Float switch (connected from mains water backup unit to the underground tank)
- 100mm diameter duct pipe to contain; float sensor cable, power cable for pump
- 100mm diameter drainage pipe connected from downpipes to the inlet at the top of the tank (all downpipes brought into one pipe for connection to the filter)
- 100mm diameter pipe for overflow from the tank to mains drainage network or soakaway
- Header tank package
4. Freeflush Eco Plus Package
The reliable domestic solution with a submersible pump and header tank system
- Simple & quick to install
- Minimises the top up water required
Eco Plus scope of supply:
- Underground tank (choice of tanks available, sizes vary according to property type)
- Telescopic lid (choice of telescopic lid available, depending on tank location)
- Minimax filter
-
Mains water feeding console 15/4
